Product Details:
|
Product Name: | 3m Self Propelled Aerial Work Scissor Lifting Platform | Model: | GTJZD03 |
---|---|---|---|
Max Lifting Height: | 3m | Max Working Height: | 5m |
Platform Size: | 1290*700mm | Rated Loading Capacity: | 240kg |
Overall Size: | 1435*760*1900mm | Platform Extension Length: | 600mm |
Certification: | CE, ISO, SGS | Voltage(v/v/hz): | 380/220/50 |
Application: | Widely | Lifting System: | Electric Hydraulic |
Control: | Double Controller | Drive Mode: | Hydraulic Cylinder+motor |
Self Propelled 4-16m Aerial Work Platform 6m 8m 10m 12m 14m Skylift Mobile Lifter Scaffolding Hydraulic Scissor Lift Platform
Product Specifications:
Model | Platform Size (mm) |
Rated loading Capacity (kg) | Max Lifting Height (m) | Max Working Height (m) | Overall Size (mm) |
Platform Extension Length (mm) | Power (KW) |
Net Weight (kg) |
GTJZD03 | 1290*700 | 240 | 3 | 5 | 1435*760*1900 | 0.6 | 900 | |
GTJZD04 | 1290*700 | 240 | 4 | 6 | 1440*760*2030 | 0.6 | 950 | |
GTJZ06 | 1670*740 | 230 | 6 | 8 | 1850*790*2200 | 0.9 | 3.3 | 1530 |
GTJZ-6A | 2300*810 | 380 | 6 | 8 | 2480*810*2180 | 0.9 | 3.3 | 1880 |
GTJZ-6 | 2300*1130 | 550 | 6 | 8 | 2480*1190*2190 | 0.9 | 3.3 | 2150 |
GTJZ-8A | 2260*810 | 230 | 8 | 10 | 2480*850*2300 | 0.9 | 3.3 | 2030 |
GTJZ-8 | 2260*1130 | 450 | 8 | 10 | 2480*1190*2320 | 0.9 | 3.3 | 2300 |
GTJZ-10 | 2290*1130 | 320 | 10 | 12 | 2495*1181*2450 | 0.9 | 3.3 | 2530 |
GTJZ-12 | 2290*1130 | 320 | 11.8 | 13.8 | 2495*1187*2585 | 0.9 | 4.5 | 2870 |
GTJZ-14 | 2670*1130 | 227 | 13.8 | 15.8 | 2840*1400*2595 | 0.9 | 4.5 | 3340 |
Our Advantage
1.Factory Direct Sale--Lowest Price
2.1 piece can be customized
3.15 years of production experience
4.CE and ISO9001
RFQ:
1. Are you an original manufacturer?
Yes, we are a professional manufacturer of scissor lifts, with our factory located in Jiyang District, Jinan City, Shandong Province.
2. What is our delivery time?
Normally, we have inventory of standard products. If not, we need 7-10 days to produce standard products and 10-15 days to produce customized products. The specific negotiation time is based on the various styles customized for the products.
3. What is our guarantee?
We provide you with a one-year warranty period, during which we can provide you with non human damaged parts for free. We provide online services 24 hours a day to solve any problems that arise. We adhere to customer first and quality first.
4. Do we accept customization
Of course, we customize the products according to your requirements and can meet your needs. We can do OEM and ODM for you.
5. What is our minimum order quantity?
It is a unit. But if you order more, we have a good discount.
