Product Details:
|
Product Name: | Fixed Electric Hydraulic Scissor Lifting Platform | Model: | DG1007 |
---|---|---|---|
Rated Loading Capacity: | 1000kg | Platform Size: | 1700*1500mm |
Lifting Height: | 340-1300mm | Net Weight: | 400kg |
Warranty: | 12 Months | Machinery Test Report: | Provided |
Power Source: | Electric | Keywords: | Constrruction Hoist |
Electric Hydraulic Scissor Lift Platform Simple Steel Construction For Lifting Goods Fixed Electric Lifting Tables
Model |
Rated loading capacity (kg) |
Platform size (mm) |
Min. Height (mm) |
Max. Height (mm) |
Lifting time (s) |
Net weight (kg) |
DG1001 |
1000 |
1300*820 |
205 |
990 |
20~25 |
180 |
DG1002 |
1000 |
1600*1000 |
205 |
990 |
20~25 |
200 |
DG1003 |
1000 |
1700*850 |
240 |
1300 |
30~35 |
220 |
DG1004 |
1000 |
1700*1000 |
240 |
1300 |
30~35 |
230 |
DG1005 |
1000 |
2000*850 |
240 |
1300 |
30~35 |
230 |
DG1006 |
1000 |
2000*1000 |
240 |
1300 |
30~35 |
250 |
DG1007 |
1000 |
1700*1500 |
240 |
1300 |
30~35 |
400 |
DG1008 |
1000 |
2000*1700 |
240 |
1300 |
30~35 |
470 |
DG2001 |
2000 |
1300*850 |
230 |
1000 |
50~60 |
260 |
DG2002 |
2000 |
1600*1000 |
230 |
1000 |
50~60 |
290 |
DG2003 |
2000 |
1700*850 |
250 |
1300 |
50~60 |
320 |
DG2004 |
2000 |
1700*1000 |
250 |
1300 |
50~60 |
330 |
DG2005 |
2000 |
2000*850 |
250 |
1300 |
50~60 |
330 |
DG2006 |
2000 |
2000*1000 |
250 |
1300 |
50~60 |
350 |
DG2007 |
2000 |
1700*1500 |
250 |
1400 |
50~60 |
460 |
DG2008 |
2000 |
2000*1800 |
250 |
1400 |
50~60 |
550 |
DG4001 |
4000 |
1700*1200 |
250 |
1050 |
55~65 |
410 |
DG4002 |
4000 |
2000*1200 |
250 |
1050 |
55~65 |
450 |
DG4003 |
4000 |
2000*1000 |
300 |
1400 |
55~65 |
520 |
DG4004 |
4000 |
2000*1200 |
300 |
1400 |
55~65 |
540 |
DG4005 |
4000 |
2200*1000 |
300 |
1400 |
55~65 |
530 |
DG4006 |
4000 |
2200*1200 |
300 |
1400 |
55~65 |
560 |
DG4007 |
4000 |
1700*1500 |
300 |
1300 |
55~65 |
630 |
DG4008 |
4000 |
2200*1800 |
300 |
1300 |
55~65 |
720 |
Product Safety
1. What safety precautions should be taken when using electric machinery?
* Before using, be sure to carefully read the product manual to understand the correct operation method and safety warnings.
* Wear appropriate personal protective equipment such as safety helmets, goggles, and gloves.
* Ensure a safe working environment and stay away from flammable, explosive items and water sources.
* Do not use electric machinery in a damp or rainy environment.
* Regularly check the power cord, plug, and switch of the equipment to ensure they are in good condition.
2. Does electric machinery have safety certification?
* Our electric machinery has passed international authoritative safety certifications such as CE and UL to ensure the safety and reliability of the products.
Sefety precaution
1. Explosion-proof valves
2. explosion proof pipe
3. spill proof by sealed elements
3. Emergency decline by flow valve
4. Overload protection locking device.
5. Automatic Safety sensor:stop when come across barriers.
Why Choose a Stationary Scissor Lift Platform?
1. Improves Loading/Unloading Efficiency
Perfect for warehouses, factories, and logistics centers – it lifts goods quickly between different heights, saving time and labor.
2. Space-Saving and Flexible Installation
Can be pit-mounted or placed directly on the floor without taking up too much space. Ideal for fixed workstations.
3. Bridges Height Gaps with Docks, Vehicles, or Lines
Solves the height difference problem between ground level, loading docks, trucks, and platforms smoothly and safely.
4. Versatile for Industrial Applications
Whether it’s used in production, packaging, or storage handling – the scissor lift performs reliably and stably.
