Product Details:
|
Product Name: | Semi Electric Aerial Work Scissor Lifting Platform | Model: | QYCY0.5-6 |
---|---|---|---|
Max Lifting Height: | 6m | Max Working Height: | 8m |
Rated Loading Capacity: | 500kg | Platform Size:: | 2100*830mm |
Machine Overall Size: | 2250*950*1200mm | Net Weight: | 880kg |
Voltage: | 220-480V According To Your Local Requirements | Warranty: | 12 Months |
4-18m Semi Electric Lift Table Aerial Work Electric Scissor Lifting Mobile Hydraulic Vertical Scissor Lift Platform
Model |
Platform Size (mm) |
Loading Capacity (kg) |
Lifting Height (m) |
Overall Size (mm) |
Weight (kg) |
QYCY0.5-4 |
2100*830 |
500 |
4 |
2250*950*1100 |
800 |
QYCY0.5-6 |
2100*830 |
500 |
6 |
2250*950*1200 |
|
QYCY0.5-7 |
2100*830 |
500 |
6.8 |
2250*950*1200 |
970 |
QYCY0.5-8 |
2100*930 |
500 |
8 |
2250*1060*1380 |
1050 |
QYCY0.5-9 |
2100*930 |
500 |
9 |
2250*1060*1500 |
|
QYCY0.5-10 |
2100*1230 |
500 |
10 |
2250*1350*1530 |
1360 |
QYCY0.3-11 |
2100*1230 |
300 |
11 |
2250*1350*1650 |
1400 |
QYCY0.5-12 |
2550*1530 |
500 |
12 |
2796*1670*1750 |
2260 |
QYCY0.5-14 |
2812*1530 |
500 |
14 |
3067*1730*1810 |
2486 |
QYCY0.3-16 |
2812*1600 |
300 |
16 |
3067*1810*2080 |
3063 |
QYCY0.3-18 |
3070*1600 |
300 |
18 |
3321*1810*2080 |
3900 |
QYCY1.0-4 |
2100*1200 |
1000 |
4 |
2250*1350*1180 |
1250 |
QYCY1.0-6 |
2100*1200 |
1000 |
6 |
2250*1350*1300 |
1400 |
QYCY1.0-8 |
2100*1200 |
1000 |
8 |
2250*1350*1420 |
1585 |
QYCY1.0-10 |
2100*1200 |
1000 |
10 |
2250*1350*1530 |
1700 |
QYCY1.0-12 |
2550*1530 |
1000 |
12 |
2796*1700*1780 |
2560 |
QYCY1.0-14 |
2812*1600 |
1000 |
14 |
3067*1810*1900 |
3230 |
QYCY1.5-6 |
2100*1530 |
1500 |
6 |
2250*1750*1530 |
1780 |
QYCY1.5-8 |
2100*1530 |
1500 |
8 |
2250*1750*1690 |
2070 |
QYCY1.5-10 |
2100*1500 |
1500 |
10 |
2250*1750*1850 |
2250 |
QYCY2.0-6 |
2100*1530 |
2000 |
6 |
2250*1750*1530 |
1780 |
QYCY2.0-8 |
2100*1530 |
2000 |
8 |
2250*1750*1690 |
2070 |
QYCY2.0-10 |
2100*1530 |
2000 |
10 |
2250*1750*1850 |
2250 |
Product Advance
Performance
* Stable & Efficient: The scissor structure ensures smooth lifting, strong load - bearing. Ideal for factory, warehousing,
construction tasks like material lifting and high - altitude work.
* Electric - Driven: Powerful, low - noise, eco - friendly electric system. Allows precise control of height and speed for easy
use.
Quality
* Durable: High - strength steel and strict manufacturing. Key parts (hydraulic pumps, motors) from top brands, ensuring long
life and low faults.
* Safe: Multiple protections (overload, emergency descent, guardrails, anti - slip) keep operators safe.
Customization & Service
* Customizable: Tailor - made for different heights, loads, special environments (explosion - proof, anti - corrosion) to fit
diverse needs.
* Full - service: One - stop support from pre - sales design, in - sales follow - up, to post - sales installation and
maintenance. Efficient for overseas orders too.
Choose our lifts for efficiency, safety and reliability, boosting your operation and cutting costs!
