Characteristic

1.1

Model

CBD-15ZX

CBD-20ZX

1.2

Power Type

Battery

1.3

Operation Type

Walking

1.4

Rated Load Capacity

Q

1500kg

2000kg

1.5

Load Center

C

600mm

Weight

2.1

Weight with battery

kg

195

205

Wheel

3.1

Material

PU

3.2

Back wheel

Ø80*70

Ø80*70

3.3

Driving wheel

Ø210*75

Ø210*75

3.4

Balance wheel

Ø75*47

3.5

Rear wheelbase

mm

410/525

410/525

3.6

Front wheelbase

mm

450

Size

4.1

Lifting height

mm

200

200

4.2

Body length

mm

1750

4.3

Overall width

mm

680

4.4

Fork size

mm

550*165*1150

680*165*1220

4.5

Min ground clearance

mm

25

4.6

Channel width, pallet size 800*1200

mm

1800

1800

4.7

Channel width, pallet size 1000*1200

mm

1900

1900

4.8

Turning radius

mm

1475

Performance

5.1

Driving sped, load/ unload

Km/h

4.5/6.2

5.2

Lifting speed, load/ unload

M/s

0.3/0.5

0.3/0.53

5.3

Falling  speed, load/ unload

M/s

0.48/0.37

0.49/0.36

5.4

Readability, load/ unload

%

3/6

4/8

5.5

Brake

Electromagnetic braking

Motor

6.1

Driving motor

KW

0.75

1.3

6.2

Lifting motor

KW

0.8

0.8

6.3

Battery capacity

V/Ah

2*12/60

2*12/85
