3 Ton 5 Ton Diesel Forklift CPC-30 3000kg Diesel Engine Forklift Truck 3m Lifting Height Solid Tire for Construction Warehouse

Name: 3 Ton 5 Ton Diesel Forklift CPC-30 3000kg Diesel Engine Forklift Truck 3m Lifting Height Solid Tire for Construction Warehouse
Brand: Wuxi Chengxin Machinery Equipment Co.,Ltd.
SKU: CPC30
Price: 10425.00 USD
Availability: InStock

All Products

Lifting platform
(43)

Pallet stacker
(44)

Forklift
(12)

Pallet Trucks
(19)

Aerial Working Lifting Machine
(31)

Vacuum Lift Lifter
(2)

Certification

I'm Online Chat Now

3 Ton 5 Ton Diesel Forklift CPC-30 3000kg Diesel Engine Forklift Truck 3m Lifting Height Solid Tire for Construction Warehouse

Large Image : 3 Ton 5 Ton Diesel Forklift CPC-30 3000kg Diesel Engine Forklift Truck 3m Lifting Height Solid Tire for Construction Warehouse

Product Details:

Place of Origin:	China
Brand Name:	CX
Certification:	CE; ISO
Model Number:	CPC30

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	USD 7350-13500/Set FOB Qingdao port
Packaging Details:	Plywood pallet or as your actual requirements.
Delivery Time:	In general, within 7-15 days.
Payment Terms:	T/T,Western Union,L/C
Supply Ability:	5000 sets per month.

Contact Now

3 Ton 5 Ton Diesel Forklift CPC-30 3000kg Diesel Engine Forklift Truck 3m Lifting Height Solid Tire for Construction Warehouse

Description

Product Name:	3 Tons Diesel Forklift Trucks	Condition:	New
Fork Length:	1020mm Or Optional	Fork Width:	100mm
Forklift Turning Radius:	2240 Mm, 1950 Mm, 2170 Mm	Load Centre Distance:	1 000 Mm, 800 Mm
Mast Type:	Three Stage Mast, Single Stage Mast, Two Stage Mast	Power Source:	Diesel
Applicable Industries:	Hotels, Building Material Shops, Machinery Repair Shops, Manufacturing Plant	Overall Dimensions:	260011502055 Mm
Capacity:	3000KG -10000KG	Mast:	2 Stage/3 Stage Optional
Color:	Customer Demanded	Lifting Height:	3000mm- 7000mm Customized

3 Ton 5 Ton Diesel Forklift CPC-30 3000kg Diesel Engine Forklift Truck 3m Lifting Height Solid Tire for Construction Warehouse

3 Ton 5 Ton Diesel Forklift CPC-30 3000kg Diesel Engine Forklift Truck 3m Lifting Height Solid Tire for Construction Warehouse

Product Parameters

Basic parameters
Model		CPC30-K		CPC35-K
Power type		diesel		diesel
Rated capacity	kg	3000		3000
Load center	mm	500		500
Characteristic & Dimension
Lifting height	mm	3000		3000
Free lift height	mm	110		110
Fork size (LWT)	mm	107012245		107012550
Mast tilt angle (F/R)	Deg	6°/12°		6°/12°
Front overhang	mm	450		450
Rear overhang	mm	525		550
Min ground clearance	mm	115		115
Length to face of fork (without fork)	mm	2750		2750
Overall width	mm	1210		1210
Min mast height	mm	2060		2060
Max mast height	mm	4065		4065
Overhear guard height	mm	2090		2090
Min turning radius	mm	2600		2600
Min straight angle stacking aisle width	mm	2160		2160
Performance
Travel speed (unload)	Km/h	19		19
Lifting speed (load)	mm/second	430		400
Lowering speed (load)	mm/second	450		450
Maximum Traction	KN	19		19
Tyre
Maximum climbing angle (load)	%	15		15
Front tire	mm	28x9-15-12PR		28x9-15-12PR
Rear tire	mm	6.50-10-10PR		6.50-10-10PR
Front tire tread	mm	1000		1000
Rear tire tread	mm	980		980
Wheelbase	mm	1750		1750
Weight
Self weight	kg	4310		4750
Transmission
Engine model		4D29V41
Engine manufacturer			Xinchai brand
Fuel tank capacity	L	60		60
Transmission		CHINA		CHINA

3 Ton 5 Ton Diesel Forklift CPC-30 3000kg Diesel Engine Forklift Truck 3m Lifting Height Solid Tire for Construction Warehouse

RFQ:

1. What about your delivery time?

May I know how soon I can get the machine after the deposit? Usually, if the quantity is less than 20 units, we can finish the production in 15-20 days. We will try our best to offer the machines to you as soon as possible.

2. What is about your warranty?

12 months. If during the warranty, we will send to you for free by courier.

3. Can provide customized products?

Yes, we can provide customized products according to your requirement.

4. Which is the port of yours?

We ship the goods from Shanghai, Ningbo, Qingdao ports, can be arranged according to custom-er requirements.

5. What can I get from cooperating with you?

Unique products, with customized service. Timely production and delivery, time is money. Market protection service, long term business strategy.
