Product Details:
|
Product Name: | Manual Hydraulic Pallet Trucks | Model: | CXB5000 |
---|---|---|---|
Rated Loading Capacity: | 5000kg | Fork Outside Width: | 550/685mm |
Fork Length: | 1150/1220mm | Net Weight: | 135-147kg |
Lifting Height: | 85-190mm | Small Wheel Size: | Ø82*67mm |
Large Wheel Size: | Ø180*50mm | Fork Width: | 180mm |
High Quality Warehouse Material Handling Manual Forklift 5 Ton Hand Pallet Jack Hand Hydraulic Pallet Trucks
Specifications:
Model |
CXB2000 |
CXB2500 |
CXB3000 |
CXB5000 |
Rated loading capacity |
2000kg |
2500kg |
3000kg |
5000kg |
Fork outside width |
550/685mm |
550/685mm |
550/685mm |
550/685mm |
Fork length |
1150/1220mm |
1150/1220mm |
1150/1220mm |
1150/1220mm |
Fork width |
160mm |
160mm |
160mm |
180mm |
Small wheel size |
Ø70*60mm |
Ø80*70mm |
Ø80*60mm |
Ø82*67mm |
Large wheel size |
Ø160*50mm |
Ø180*50mm |
Ø180*50mm |
Ø180*50mm |
Max fork height |
190mm |
198mm |
200mm |
190mm |
Min fork height |
75mm |
83mm |
82mm |
85mm |
Self height |
56-62kg |
61-65kg |
78-81kg |
135-147kg |
Product Features:
1.The pallet lift truck has a rugged construction and will not bend under heavy loads.
2.Its steel chassis can take about 25 percent more weight than comparable models of this size.
3.The hydraulics are protected from dust and are well suited to long, hard working days, with a minimum of service.
4.The wheels increase handling capacity with their low rolling resistance.
5.The tiller also has a large steering angle on both sides.
6.It's therefore easy to maneuver this hydraulic hand pallet truck in a tight space, such as the truck loading bays.
7.A broad tiller handle protects the hands from injury.
Why Choose Us
1. Experiences
We have 25 years experiences of producing material handling equipment.
2. Team
We enjoy a good team of Sales department and professional design team.
3. Fully customized service
1) Support customization of color, logo, fork length and other machine attributes;
2) Welcome to customize non-standard models.
4. R&D new products
1) We are specializing in manufacturing various 380 items, including hoisting machinery, financial equipments, electric winch, electric truck, electric forklift and hydraulic truck, etc.
2)The r&d team constantly develops new products according to customer needs
5. Product quality certification
1) We have passed the certificate of ISO9001:2015 quality system and BSCI.
2) Our products have got CE, GS, ROHS, CB, UL, CUL and FCC approvals.
3)Our products got the national special equipment production license and industrial products production license.
