Full Electric Pallet Stacker 2000kg 3000mm Capacity Loading Hydraulic Walking Forklift With Charging Battery

Certification
China Wuxi Chengxin Machinery Equipment Co.,Ltd. certification
I'm Online Chat Now

Full Electric Pallet Stacker 2000kg 3000mm Capacity Loading Hydraulic Walking Forklift With Charging Battery

Full Electric Pallet Stacker 2000kg 3000mm Capacity Loading Hydraulic Walking Forklift With Charging Battery
Full Electric Pallet Stacker 2000kg 3000mm Capacity Loading Hydraulic Walking Forklift With Charging Battery Full Electric Pallet Stacker 2000kg 3000mm Capacity Loading Hydraulic Walking Forklift With Charging Battery Full Electric Pallet Stacker 2000kg 3000mm Capacity Loading Hydraulic Walking Forklift With Charging Battery Full Electric Pallet Stacker 2000kg 3000mm Capacity Loading Hydraulic Walking Forklift With Charging Battery Full Electric Pallet Stacker 2000kg 3000mm Capacity Loading Hydraulic Walking Forklift With Charging Battery Full Electric Pallet Stacker 2000kg 3000mm Capacity Loading Hydraulic Walking Forklift With Charging Battery

Large Image :  Full Electric Pallet Stacker 2000kg 3000mm Capacity Loading Hydraulic Walking Forklift With Charging Battery

Product Details:
Place of Origin: China
Brand Name: CX
Certification: ISO, CE
Model Number: CDDP20-30
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: USD 1689-1899/set FOB Shanghai port
Packaging Details: packaged by plywood pallet or plywood box, and with preservative film, it can stop the salt sea water enter into the machine and make the machine corrosion.
Delivery Time: Within 10-15 days
Payment Terms: L/C,T/T,Western Union,MoneyGram
Supply Ability: 5000 sets per month

Full Electric Pallet Stacker 2000kg 3000mm Capacity Loading Hydraulic Walking Forklift With Charging Battery

Description
Product Name: Walking Type Electric Hydraulic Pallet Stacker Model: CDDP20-30
Rated Loading Capacity: 2000kg Overall Size: 2020*800*2020mm
Max Lifting Height: 3000mm Fork Length: 1150mm
Net Weight: 560kg Forklift Wheelbase: 1335mm
Applicable Industries: Building Material Shops, Machinery Repair Shops... Fork Outside Width: 550/685mm
Warranty: 12 Months Battery Capacity: 2*12V/85Ah

Full Electric Pallet Stacker 2000kg 3000mm Capacity Loading Hydraulic Walking Forklift With Charging Battery


Full Electric Pallet Stacker 2000kg 3000mm Capacity Loading Hydraulic Walking Forklift With Charging Battery 0

Electric stacker is a new choice for medium stacker operations of 1500-2000kg. Compact chassis, light weight, small turning radius, more flexible and practical in material handling and logistics transportation.
Multi-functional smart control handle includes accelerator, reverse safety button, drop release lever and power indicator, and has the function of switching mode drive when the handle is upright.


Specifications

Rated loading capacity

1500kg

2000kg

Max lifting height

1600/2000/2500/3000/3500mm

Mast extension height

2080/2470/2970/3470/4070mm

Overall height

2080/1580/1830/2080/2280mm

Overall length

1900/2020/2020/2020/2020mm

Overall width

800mm

Weight with battery

488/430/476/500/530kg

438/460/506/560/590kg

Fork size

70*165*1150mm

Channel width with pallet 800*1200mm

2537mm

Channel width with pallet 1000*1200mm

2468mm

Turning radius

1600mm

Driving speed, load/ unload

4.2/5.6km/s

4/5.2km/h

Lifting speed, load/ unload

0.105/0.148m/s

0.095/0.156m/s

Falling speed, load/ unload

0.125/0.117m/s

0.115/0.110m/s

Brake

electromagnetic

Driving motor

0.75kw

1.0kw

Lifting motor

2.2kw

2.2kw

Battery capacity

2*12V/85Ah

2*12V/85Ah


Full Electric Pallet Stacker 2000kg 3000mm Capacity Loading Hydraulic Walking Forklift With Charging Battery 1

Full Electric Pallet Stacker 2000kg 3000mm Capacity Loading Hydraulic Walking Forklift With Charging Battery 2

Full Electric Pallet Stacker 2000kg 3000mm Capacity Loading Hydraulic Walking Forklift With Charging Battery 3

Full Electric Pallet Stacker 2000kg 3000mm Capacity Loading Hydraulic Walking Forklift With Charging Battery 4

Full Electric Pallet Stacker 2000kg 3000mm Capacity Loading Hydraulic Walking Forklift With Charging Battery 5

Full Electric Pallet Stacker 2000kg 3000mm Capacity Loading Hydraulic Walking Forklift With Charging Battery 6

Full Electric Pallet Stacker 2000kg 3000mm Capacity Loading Hydraulic Walking Forklift With Charging Battery 7

Full Electric Pallet Stacker 2000kg 3000mm Capacity Loading Hydraulic Walking Forklift With Charging Battery 8

Full Electric Pallet Stacker 2000kg 3000mm Capacity Loading Hydraulic Walking Forklift With Charging Battery 9

Full Electric Pallet Stacker 2000kg 3000mm Capacity Loading Hydraulic Walking Forklift With Charging Battery 10


Full Electric Pallet Stacker 2000kg 3000mm Capacity Loading Hydraulic Walking Forklift With Charging Battery 11


What benefits can our forklifts bring you?

1. Our products can meet your needs in any model, tonnage, and color, allowing you to better complete your work.

2. The electric forklift products we can sell in the United States and Europe have passed CE certification, and the core components comply with European and American standards.
3. We have strict after-sales guarantee, if parts are damaged during transportation, we can provide parts for free
4.We are professional manufacturers who can provide customized services according to your needs


Packages & Shipping

Machine is packaged by plywood pallet or plywood box, and with preservative film, it can stop the salt sea water enter into the machine and make the machine corrosion.

Full Electric Pallet Stacker 2000kg 3000mm Capacity Loading Hydraulic Walking Forklift With Charging Battery 12

RFQ

Q: Are you trading company or manufacturer ?

A:Yes, We are factory, all machine is made by ourself and we can provide customizeservice according to your requirement.

Q: Can you guarantee your quality?
A: Of course. We are the manufacture factory. More importantly, we put a high value on our reputation. Best quality is our
principle all the time. You can be assured on our production completely.

Q:What should I do if we are not able to operate the machine when we receive it?
A:Operation manual and video demonstration sent along with the machine to give instructions. Besides, we have professional after-sale group to customer's site to solve any problems.


Full Electric Pallet Stacker 2000kg 3000mm Capacity Loading Hydraulic Walking Forklift With Charging Battery 13
