Fast Delivery Hydraulic Forklift Electric Truck 1.5ton 2ton Load Capacity Manufacture 2.5 Ton 3 Ton Fork Lift Truck Crane Forklifts

Large Image : Fast Delivery Hydraulic Forklift Electric Truck 1.5ton 2ton Load Capacity Manufacture 2.5 Ton 3 Ton Fork Lift Truck Crane Forklifts

Product Details:

Place of Origin:	China
Brand Name:	CX
Certification:	CE, ISO, SGS
Model Number:	CPC10

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	USD3400-6500/set
Packaging Details:	Standard sea worthy package by plywood pallet.
Delivery Time:	Within 10-15 days
Payment Terms:	T/T,L/C
Supply Ability:	5000 sets per month

Contact Now

Fast Delivery Hydraulic Forklift Electric Truck 1.5ton 2ton Load Capacity Manufacture 2.5 Ton 3 Ton Fork Lift Truck Crane Forklifts

Description

Product:	1 Ton Electric Forklifts	Rated Loading Capacity:	1000kg
Standard Lifting Height:	3000mm	Battery:	60V/70Ah Lead Acid Battery
Terrain Adaptability:	Indoor Flooring, Offroad, Rough Terrain, Outdoor Pavement	Mast Type:	Three-Stage Mas, Two-Stage Mast
Operating Mode:	Seated Operation	Drive Type:	Fwd
Fork Length:	1050mm	Forklift Overall Size:	195011502100mm
Net Weight:	1800kg	Forklift Tyre:	Solid Tire
Travel Speed ( Laden):	10km/h	Grade Ability （laden):	0.4
Travel Speed ( Unladen):	12km/h	Grade Ability（unladen):	0.36
Mast Tilt Angle (Forward Tilt-Rear Tilt):	6°/10°	Applicable Industries:	Food & Beverage Factory, Food & Beverage Shops, Farms, Energy & Mining, Building Material Shops, Construction Works , Manufacturing Plant, Food Shop, Other

Fast Delivery Hydraulic Forklift Electric Truck 1.5ton 2ton Load Capacity Manufacture 2.5 Ton 3 Ton Fork Lift Truck Crane Forklifts

Fast Delivery Hydraulic Forklift Electric Truck 1.5ton 2ton Load Capacity Manufacture 2.5 Ton 3 Ton Fork Lift Truck Crane Forklifts

1 Ton Electric Forklift Configuration Sheet
1 ton of high-end heavy-duty equipment
Basic parameters
Model	CPD10 (Self weight 1.8 tons)
Size	195011502100mm
Lift height	3000mm (customizable height)
Forklift forks	One piece forging and thickening fork (multiple size available) national standard hanging fork distance
Forklift paint	Automotive grade baking paint Moisture proof and rust proof primer, two coats of topcoat, durable and colorfast
POWER SYSTEM
The entire series comes standard with a one key adjustment function for high and low forklift
Battery	5 Chaowei maintenance-free battery (60V/70Ah)
Charging time	6-8 hours
Continuous working hours	About 6 hours
Drive motor	National standard 3KW full AC brushless motor
Lift motor	National standard 3KW full AC brushless motor
The motor is assembled with all copper wires inside, with no noise, fact heat dissipation, full enclosed internal structure, sustainable operation, with gentle slope and steep descent function and strong power.
Controller	Fully imported chip dual controller Dual independent controllers with built-in fault alarm and independent heat dissipation
CORE EQUIPMENT
High temperature protection fot the entire forklift wiring harness, dual layer protection for hydraulic component joints and H-heads
Front axle	Heavy duty cast steel front axle
Rear axle	Thickened forklift specialized suspension integrated rear axle
Forklift truck door frame	National standard C-sharped steel double hydraulic forklift dedicated door frame
Chain	5-piece bite chain
Hydro-cylinder	Dual hydraulic cylinder Adopting imported double-layer oil seals, the inner wall of the cylinder is processed with a smooth surface for secondary processing, without oil leakage or seepage
Oil Pipe	Double layer steel wire high-pressure resistent oil pipe, external wear-resistent protective cover
CONTRAL SYSTEM
Steering system	Hydraulic power steering
Braking system	Oil brake, handbrake
Tire	Front wheel 500-8 (solide tire) Rear wheel 400-8 (solide tire)
Lighting fixtures, left and right turn signals, brake lights, driving lights, electric horns, etc.
Multi functional LCD instrument panel, password swipe start, automatic power-off upon leaving the seat.
220V intelligent charger with intelligent voltage regulation and automotic power-off when fully charged.

Fast Delivery Hydraulic Forklift Electric Truck 1.5ton 2ton Load Capacity Manufacture 2.5 Ton 3 Ton Fork Lift Truck Crane Forklifts

RFQ

1)Why should I choose your products over others?

Our products deliver outstanding value: premium quality at a competitive price point.

2)Is customization available for logos and colors?

Absolutely! We welcome custom sample orders to match your brand identity.

3)What additional services does your company offer?

We provide reliable after-sales support and expedited delivery to meet your needs.

4)What is your minimum order quantity ?

We have flexible MOQ requirements-most products have no MOQ, and sample orders are always available.

5)How long is the typical delivery lead time?

For small orders, we maintain stock materials to ensure fast shipment. Customized orders are usually fulfilled within 15 working days after payment confirmation.

6)Do your products have relevant certificates for export?

Yes, our products are equipped with required export certificates to meet different regional market standards.
